PEUGEOT BOXER 435 HEAVY L3 DIESEL

Emissions - ICE

• HC
  Not Available
• Standard Emissions
  EURO 6
• WLTP - CO2 (g/km) - Comb - TEH
  306
• WLTP - CO2 (g/km) - Comb - TEL
  169

Engine and Drive Train

• Automatic Transmission
  No
• Bore
  83.8
• Catalytic Convertor
  Yes
• CC
  2184
• Cooling System
  WATER
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Engine Layout
  FRONT TRANSVERSE
• Engine Make
  Not Available
• Fuel Delivery
  COMMON RAIL
• Fuel Type
  DIESEL
• Gears
  6 SPEED
• Manual Transmission
  Yes
• Number of Valves
  16
• Stroke
  99
• Valve gear
  DOHC

Fuel Consumption - ICE

• EC
  No
• WLTP - FC (l/100km) - Comb - TEH
  11.6
• WLTP - FC (l/100km) - Comb - TEL
  6.4
• WLTP - MPG - Comb - TEH
  24.4
• WLTP - MPG - Comb - TEL
  44.1

General

• Alternative Fuel Qualifying
  No
• Did at least one aspect of this vehicles safety give cause for concern?
  No
• Badge Engine CC
  2.2
• Badge Power
  140
• Based On ID
  Not Available
• Battery AH
  Not Available
• Battery Volts
  12
• Chassis Engine Number
  Not Available
• Clutch
  SINGLE DRY PLATE
• Coin Description
  Not Available
• Coin Gross Vehicle Weight Code
  Not Available
• Coin Power Output Code
  Not Available
• Coin Series
  Not Available
• Coin Wheelbase Description Code
  Not Available
• Coin Wheelbase Name Code
  Not Available
• Exhaust System
  CATALYTIC CONVERTER
• Front Brakes
  VENTILATED DISCS
• Front Suspension
  MACPHERSON STRUTS
• Generation Mark
  3
• Ghost model for valuation purposes
  No
• NCAP Adult Occupant Protection %
  Not Available
• NCAP Child Occupant Protection %
  Not Available
• NCAP Overall Rating - Effective February 09
  Not Available
• NCAP Overall Rating - LCV
  5 Star
• NCAP Pedestrian Protection %
  Not Available
• NCAP Safety Assist %
  Not Available
• Rear Brakes
  VENTILATED DISCS
• Rear Suspension
  LEAF SPRINGS
• Relative Height
  H1
• Relative Length
  L3
• Running Cost League Headings
  LARGE
• Service Interval Frequency - Months
  24
• Service Interval Mileage
  16000
• Special Edition
  No
• Special Order
  No
• Steering
  PAS RACK AND PINION
• This vehicle is classed as a car for VED purposes
  No
• VAT qualifying vehicle - Seek advice from HMRC
  No
• Vehicle Homologation Class
  N1
• Vin/Frame No.
  Not Available

Performance

• BHP
  140
• Engine Power KW
  103
• Engine Power RPM
  3500
• Engine Torque LBS.FT
  258
• Engine Torque MKG
  35.7
• Engine Torque NM
  350
• Engine Torque RPM
  1400

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  No
• Automatic Clutch
  No
• Plated 3rd Axle
  Not Available
• Plated 4th Axle
  Not Available
• Space Saver?
  No
• Tyre Make
  Not Available
• Tyre Size Front
  215/75 R16
• Tyre Size Rear
  215/75 R16
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  Not Available
• Wheel Type
  16" STEEL

Vehicle Dimensions

• Front Overhang
  948
• Height
  2153
• Length
  5943
• Load Deck Height
  Not Available
• Load Height
  Not Available
• Load Length
  Not Available
• Load Space Width Between Wheel Arches
  Not Available
• Load Width
  Not Available
• Lower Rear Door Width
  Not Available
• Rear Door Height
  Not Available
• Rear Overhang
  860
• Side Load Door Height
  Not Available
• Side Load Door Width
  Not Available
• Turning Circle - Kerb to Kerb
  14.3
• Upper Rear Door Width
  Not Available
• Wheelbase
  4035
• Width (excluding mirrors)
  2050
• Width (including mirrors)
  2690

Weight and Capacities

• Boot Capacity Saloons
  Not Available
• Fuel Tank Capacity (Litres)
  90
• Gross Train Weight
  6500
• Gross Vehicle Weight
  3500
• Load Space Volume
  Not Available
• Luggage Capacity (Seats Down)
  Not Available
• Luggage Capacity (Seats Up)
  Not Available
• Luggage Capacity - 2nd Row Seats Removed
  Not Available
• Luggage Capacity - 2nd Row Seats Up
  Not Available
• Luggage Capacity - 3rd Row Seats Down
  Not Available
• Luggage Capacity - 3rd Row Seats Removed
  Not Available
• Luggage Capacity - 3rd Row Seats Up
  Not Available
• Max. Towing Weight - Braked
  3000
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  1825
• No. of Seats
  3
• Payload
  1675
• Plated 2nd Axle
  2400
• Plated Front Axle
  2100
