TOYOTA PROACE L1 DIESEL

Emissions - ICE

• CO
  0.073
• HC
  Not Available
• HC+NOx
  0.065
• Noise Level dB(A)
  68
• NOx
  0.059
• Particles
  0.0004
• Standard Emissions
  EURO 6
• WLTP - CO2 (g/km) - Comb
  171
• WLTP - CO2 (g/km) - Extra High
  192
• WLTP - CO2 (g/km) - High
  146
• WLTP - CO2 (g/km) - Low
  193
• WLTP - CO2 (g/km) - Medium
  159

Engine and Drive Train

• Automatic Transmission
  No
• Bore
  75
• Catalytic Convertor
  Yes
• CC
  1499
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Engine Make
  Not Available
• Fuel Delivery
  COMMON RAIL
• Fuel Type
  DIESEL
• Gears
  6 SPEED
• Manual Transmission
  Yes
• Number of Valves
  16
• Stroke
  84.8
• Valve gear
  DOHC

Fuel Consumption - ICE

• EC
  No
• WLTP - FC (l/100km) - Comb
  6.5
• WLTP - FC (l/100km) - Extra High
  7.3
• WLTP - FC (l/100km) - High
  5.6
• WLTP - FC (l/100km) - Low
  7.4
• WLTP - FC (l/100km) - Medium
  6.1
• WLTP - MPG - Comb
  43.5
• WLTP - MPG - Extra High
  38.7
• WLTP - MPG - High
  50.4
• WLTP - MPG - Low
  38.2
• WLTP - MPG - Medium
  46.3

General

• Alternative Fuel Qualifying
  No
• Did at least one aspect of this vehicles safety give cause for concern?
  No
• Badge Engine CC
  1.5
• Badge Power
  120
• Based On ID
  Not Available
• Clutch
  Not Available
• Coin Description
  Not Available
• Coin Gross Vehicle Weight Code
  Not Available
• Coin Power Output Code
  Not Available
• Coin Series
  Not Available
• Coin Wheelbase Description Code
  Not Available
• Coin Wheelbase Name Code
  Not Available
• Front Brakes
  VENTILATED DISCS
• Front Suspension
  PSEUDO MCPHERSON
• Generation Mark
  2
• Ghost model for valuation purposes
  No
• Insurance Group 1
  Not Available
• Insurance Group 2
  Not Available
• NCAP Adult Occupant Protection %
  Not Available
• NCAP Child Occupant Protection %
  Not Available
• NCAP Overall Rating - Effective February 09
  Not Available
• NCAP Overall Rating - LCV
  4 Star
• NCAP Pedestrian Protection %
  Not Available
• NCAP Safety Assist %
  Not Available
• Rear Brakes
  DISCS
• Rear Suspension
  OBLIQUE WISHBONE
• Relative Height
  H1
• Relative Length
  L1
• Running Cost League Headings
  MEDIUM
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  5
• Vehicle Homologation Class
  N1
• Vin/Frame No.
  Not Available

Performance

• BHP
  120
• Engine Power KW
  88
• Engine Power RPM
  3500
• Engine Torque LBS.FT
  221
• Engine Torque MKG
  30.6
• Engine Torque NM
  300
• Engine Torque RPM
  1750

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  No
• Automatic Clutch
  No
• Tyre Size Front
  215/65 R16
• Tyre Size Rear
  215/65 R16
• Wheel Style
  Not Available
• Wheel Type
  16" STEEL

Vehicle Dimensions

• Front Overhang
  902
• Height
  1955
• Length
  4981
• Load Height
  1397
• Load Length
  2512
• Load Width
  1636
• Rear Overhang
  803
• Turning Circle - Kerb to Kerb
  12.4
• Turning Circle - Wall to Wall
  12.9
• Wheelbase
  3275
• Width (excluding mirrors)
  1924

Weight and Capacities

• Gross Vehicle Weight
  2656
• Load Space Volume
  5.8
• Luggage Capacity - 2nd Row Seats Removed
  2413
• Luggage Capacity - 2nd Row Seats Up
  Not Available
• No. of Seats
  3
• Plated 2nd Axle
  1618
• Plated Front Axle
  1630
